❖Specifications
|
Brand |
Blaupunkt |
Model |
Alice Springs 500 |
Display |
- 6.2″ TFT Capacitive Touch Screen
- Resolution: 800 x 480 pixel
- Brightness Control
- Clock Display
- Clock Mode
- Radio System Languages: English, Chinese, Arabic, French, Italian, Indonesia
|
Radio |
- World Tuner (switchable): Europe, America, Thailand
- Wave Bands: FM, AM
- Travelstore: RM, AM
- Band Scan / Preset Scan
- Search via Frequency
- 18 FM station, 12 AM station
|
Data Carrier |
- DVD, +/-R, +/-RW, -ROM
- CD, +/-RW, -ROM
- Type Disc-Drive: Automatic Loading
- Shock Proof Memory
- USB 2.0 Up to 32GB (Removable Storage)
- SDHC
- SD
- Storage Formats: FAT, FAT 16, FAT 32
|
DVD Player |
- Track up
- Fast Forward / Fast Rewind
- Repeat Chapter / Title
- Play / Pause / Stop / Resume
- Chapter Skip / Search
- Last Position Memory
- Root Menu
- Setup
- Title Menu
- Subtitle
- Audio Language
- Zoom / Angle
|
Media Player |
- MPEG, AVI, MP4, MOV
- JPG, PNG
- MP3
- Support ID3-tag
- Mix Track
- Track Scan
- Track Repeat
- Pause / Play
- Last Position Memory
- Language: English & Chinese (if any)
|
Bluetooth |
- Bluetooth 4.2
- Supported Profiles: HFP, PBAP, A2DP, SPP
- Up to 1 Device Pairing
- Hands-Free Calling via Microphone + Radio Speaker
- Key Function : Accept (Up to 1000 entries by Phone)
- History Call Lists: Missed, Dialed, Received Calls
- Built-In / External Microphone Ready
|
Phonelink |
- Smartphone Mirroring via Lighting Cable Apple)
- Smartphone Touch Control via USB
- iPhone Supported (Mirroring only)
- Smart Phones Supported: most of iOS 12.4 and Android 9
|
Equalizer |
- 10-Band
- Sound Preset: User, Standard, Classic, Rock, Pop, Jazz, Electric
|
Amplifier |
- 4 – Channel
- RMS Power: 4 x 22W
- Max Power: 4 x 50W
|
Input / Output |
- FM Antenna
- USB (Standard Type – A/2.0A)
- Micro SD
- Auxiliary : 1 (Front / 3.5mm jack)
- Video Input : 2 (Rear CVBS Type)
- Video Output : 1 (Rear, CVBS Type)
- 1 x Front Camera Input
- 1 x Rear Camera Input
- 2 x Audio output
- 1 x Sub Output
- Steering Wheel Control
- External Microphone
|
Accessorier |
- User Manual
- Connecting Cable
|
Power supply (12V) |
10 V ~ 16 V DC |
Current consumption |
max. 15 A |
Max. power output |
4 x 50W |
Dimension (WxLxH) |
178 x 164 x 97mm |
Weight |
1.52kg |
Operation temperature |
20°C ~ 60°C |
Warranty |
1 year |
|
