Fusion SM-F65OEM SM Series 6.5" 100W Classic Shallow Mount Marine Speaker (Pair)

$86.90

Fusion® SM Series Marine Speakers

6.5" 100-Watt Classic White Shallow Mount Marine Speaker (Pair)

Availability: In stock
SKU
010-02263-90

❖Features

OPTIMISED QUALITY AUDIO REPRODUCTION

The Fusion SM Series shallow mount speakers are designed for installations where mounting depth is limited, without compromising on sound quality and performance.

>   The unique shallow mount design features a mounting depth of only 0.94″ (24 mm).

>   A high-end acoustic fabric finish with rounded edges and contours adds style to your boat.

>   The tuned, sealed enclosure provides quality audio reproduction and protects the speaker components.

>   The mounting diameter clearance of 5.12″ (130 mm) allows it to be retrofittable with most 6.50″ speaker cutouts.

Features

>   DESIGNED AND ENGINEERED FOR THE MARINE ENVIRONMENT - The SM Series speakers have an IP65 rating for protection against dust and water ingress and have been tested to a high level of protection against salt fog and UV.

>   QUALITY MATERIALS AND ACOUSTIC ENGINEERING - The SM Series speakers incorporate high-quality materials and marine-specific design elements, ensuring they look and sound great on the water.

>   MULTIPLE MOUNTING ACCESSORIES - Three accessory mounting spacers are available (each sold separately), allowing you to mount your SM Series speakers on board with versatility and ease.

 TUNED, SEALED ENCLOSURE - The enclosure allows for installation where mounting depth is limited, without compromising sound quality. The enclosure also protects the components from damage without needing rear speaker cups, simplifying installation.

>   OPTIMISED SPEAKER DRIVER - An optimised 3″ speaker driver is incorporated into the enclosure, with all acoustic parameters precisely calculated for quality audio reproduction wherever the speaker is installed.

IN THE BOX

>   One pair of speakers (based on what you select)

>   One pair of seals

Notes: Speaker wire and Grilles not included.

Installation Recommendation

The SM Series speakers are designed for use directly with a Fusion stereo unit. Use of the speakers with an external amplifier is not recommended.

❖Specifications

Brand Fusion
Model SM-F65OEM
General
Physical dimensions (Diameter x Depth) 6.10″ x 1.81″ (155 x 46 mm)
Water and dust rating IP65
Configuration Full Range
Speaker size 6.50″
Peak power (Watts) 100 W
Sensitivity (1 W / 1 m) 84 dB
Frequency response 150 Hz-20 kHz
Nominal impedance 4 ohms
Operating temperature range 32° to 122° F (0° to 50° C)
Voice coil diameter 20 mm
Cone material Polypropylene cone with rubber surround
Compass-safe distance 96.50″ (245 cm)
Warranty 1 year
Mounting dimensions
Mounting diameter clearance 5.12″ (130 mm)
Mounting depth clearance 0.94″ (24 mm)
More Information
gtin 0753759236618
MPN 010-02263-90
Brand Fusion
