❖Features

MISTER HITCHES RAPTOR 4500KG SUPER DUTY ADJUSTABLE BALL MOUNT - LONG DROP SHANK

• 4,500kg MAX. TOW  CAPACITY.  450kg MAX. T.W.
• TESTED & COMPLIANT WITH ADR62/02.
• TESTED UP TO 6,750kg (LONGITUDINAL TENSION).
• SOLID STEEL SHANK WITH DUAL GUSSETS FOR SUPERIOR STRENGTH.
• USE WITH 50mm 3.5t OR 70mm 4.5t TOW BALLS. (sold separatly)
• REVERSIBLE SHANK & BALL PLATFORM GIVE GREATER DROP OR RISE HEIGHT.
• 16 STAGE ADJUSTMENTS MAX RISE 286mm MAX DROP 305mm. (32mm increments)
• MULTI-PIN HOLES GIVE 3 LENGTH ADJUSTMENTS. 315-340-365mm.
• H.T. 3/4” BOLTS, NYLOC LOCKING NUTS AND TOOTHED CONICAL WASHERS GIVES SUPERIOR STRENGTH.
• POWDER COATED ENAMEL FINISH GIVES GREATER PROTECTION FROM THE ELEMENTS.
• COMPATIBLE WITH HITCHMASTER DO35 & DO45, TREG, McHITCH, HITCH-EZY, ALKO, OZ HITCH 4.5T & ARK COUPLINGS.  ALSO SUITABLE FOR THE FORD RANGER SHORT SHANK TOW BAR.
• MANUFACTURED TO MISTER HITCHES STRICT QUALITY AND SPECIFICATIONS.
